The 200-300 MHz N-type connection GaN jammer modules offer reliable and efficient performance, making them a crucial tool in modern electronic warfare. Designed to operate within the 200-300 MHz frequency range, these modules provide powerful signal jamming capabilities, delivering a significant tactical advantage in complex and hostile environments.

Built with advanced Gallium Nitride (GaN) technology, these modules deliver superior power output and energy efficiency, ensuring effective signal disruption. The GaN technology enhances overall reliability and stability, allowing the jammer to function optimally even in demanding conditions.

The N-type connection allows easy integration with various systems, making these modules adaptable for military, defense, and counter-surveillance applications. Whether used for protecting sensitive communications or neutralizing threats, the jammer modules maintain operational superiority.

Advantages of Our Products:

Frequency Range: Covers the VHF band from 200 to 300 MHz, ensuring broad compatibility with a wide range of communication systems.

High Power Density: GaN-based technology offers high power density and efficient heat dissipation for sustained operation under high loads.

Durability and Efficiency: N-type GaN structure improves efficiency, reduces overall power consumption and extends the life of the device.

Enhanced Jamming Capabilities: The module is ideal for counter-communication operations, for electronic warfare, tactical field operations, and defense-grade signal jamming applications.

Compact Design: Optimized for portability and integration into larger systems, for both fixed and mobile platforms.

Number	Items	Specifications
1	Frequency Range	200-300MHz
2	Operating Voltage	28V
3	Flatness	±0.5dB
4	Output Power	47dBm
5	Current	3.6A @28V, 47dBm
6	Efficiency	45%@47dBm
7	LED State	Red
8	Operating Temperature	-30℃～85℃
9	Storage Temperature	-40℃～150℃
10	Operating Humidity	＜95%RH
11	RF PORT	N Type
12	Power Socket	15cm red/black wire
13	Shell Material	Aluminum
14	Shell Size	128.55317mm
15	Net Weight	0.25Kg
